30 Ft Wide Portable Oval Truss Storage Shelter – SP Model with UV-Resistant Fabric & Anchoring Kit

Professional 9144.0 mm (30 ft) Wide Portable Oval Truss Storage Shelter

Heavy-Duty SP-Model Galvanized Steel Building (40 ft to 85 ft Configurations)

OVERVIEW

Protect your heavy industrial investments, farm equipment, and construction materials year-round with our Professional 9144.0 mm (30 ft) Wide Portable Oval Truss Storage Shelter. Engineered for the most demanding commercial environments, this heavy-duty SP-Model structure offers unmatched strength, weather resistance, and deployment versatility. The reinforced galvanized steel oval truss frame is wrapped in a commercial-grade 10.5 oz UV-treated PE fabric cover, providing impenetrable protection against harsh sun, wind, driving rain, and heavy snow loads. Available in four massive length configurations (ranging from 12192.0 mm / 40 ft up to 25908.0 mm / 85 ft), the high-clearance interior easily accommodates towering machinery, fully loaded trailers, and oversized commercial vehicles.

SYSTEM HIGHLIGHTS

• Reinforced Oval Truss Architecture: Forged from thick galvanized steel tubing configured in a high-strength oval truss pattern, maximizing roof load capacity and aggressively resisting industrial rust and corrosion.

• Commercial 10.5 oz PE Cover: Features a heavy-duty, tear-resistant 10.5 oz polyethylene fabric canopy that is completely UV-treated and weatherproofed for reliable multi-season longevity.

• Massive Interior Clearance: The towering 4572.0 mm (15 ft) peak height allows operators to safely maneuver standard forklifts and park large agricultural combine tractors completely out of the elements.

• Extreme Weather Anchoring: Arrives complete with a heavy-duty anchoring kit engineered to secure the massive structure to concrete, dirt, or gravel, ensuring maximum stability in high-wind and storm-prone regions.

• Rapid Deployment Design: Offers a highly cost-effective and portable alternative to permanent brick-and-mortar warehouses, allowing for quick assembly on temporary job sites or permanent agricultural lots.

SPECIFICATIONS BY VARIANT

SKU	Model Designation	PE Fabric Weight	Dimensions (W x L x H)
SP304015R	SP-Model Oval Truss Shelter	10.5 oz	30 x 40 x 15 ft
SP305315R	SP-Model Oval Truss Shelter	10.5 oz	30 x 53 x 15 ft
SP306515R	SP-Model Oval Truss Shelter	10.5 oz	30 x 65 x 15 ft
SP308515R	SP-Model Oval Truss Shelter	10.5 oz	30 x 85 x 15 ft

TECHNICAL DATA (40 FT BASE MODEL)

• Overall Width: 9144.0 mm (30 ft)

• Peak Height: 4572.0 mm (15 ft)

• Available Lengths: 12192.0 mm (40 ft) / 16154.4 mm (53 ft) / 19812.0 mm (65 ft) / 25908.0 mm (85 ft)

• Cover Material: 10.5 oz UV-Treated Polyethylene (PE)

• Frame Construction: Galvanized Steel Oval Truss

• Master Box Dimensions: 2895.6 x 762.0 x 711.2 mm (114" x 30" x 28")

• Total Weight: 909.9 kg (2006 lbs)

IDEAL APPLICATIONS

• Agricultural Estates: Sheltering expensive tractors, hay bales, and seasonal harvesting equipment from severe weather degradation.

• Commercial Construction: Serving as a massive, on-site secure storage depot for building materials and heavy machinery.

• Industrial Warehousing: Instantly expanding commercial inventory storage space without the massive capital expenditure of a permanent facility.

• Fleet Management: Providing a protected outdoor service and parking bay for utility trucks, snowplows, and transit vans.
